power sockets 3/8 driver

Power Sockets – Torx® Driver TX

3/8" square drive according DIN 3121 G 10
Torx® Driver – L50
Model Item No. Size L [mm] D1 [mm] D2 [mm] L1 [mm] Pk [ea]
K3/8-T9 221650 T9 50 – 19 2.8 10
K3/8-T10 221651 T10 50 – 19 2.8 10
K3/8-T15 221652 T15 50 – 19 2.8 10
K3/8-T20 221653 T20 50 – 19 3 10
K3/8-T25 221654 T25 50 – 19 3 10
K3/8-T27 221655 T27 50 – 19 3.8 10
K3/8-T30 221656 T30 50 – 19 3.8 10
K3/8-T40 221657 T40 50 – 19 4.3 10
K3/8-T45 221658 T45 50 – 19 5 10
K3/8-T47 221659 T47 50 – 19 5 10
K3/8-T50 221660 T50 50 – 19 5.5 10
Torx® Driver – L150
Model Item No. Size L [mm] D1 [mm] D2 [mm] L1 [mm] Pk [ea]
K3/8-T20-150 221670 T20 150 – 19 3.0 –
K3/8-T25-150 221671 T25 150 – 19 3.0 –
K3/8-T27-150 221672 T27 150 – 19 3.8 –
K3/8-T30-150 221673 T30 150 – 19 3.8 –
K3/8-T40-150 221674 T40 150 – 19 4.3 –
K3/8-T45-150 221675 T45 150 – 19 5.0 –
K3/8-T47-150 221676 T47 150 – 19 5.0 –
K3/8-T50-150 221677 T50 150 – 19 5.5 –
K3/8-T55-150 221678 T55 150 – 19 5.5 –
Torx® Driver – with joint
Model Item No. Size L [mm] D1 [mm] D2 [mm] L1 [mm] Pk [ea]
KG3/8-T20 221710 T20 60 – 24 3 10
KG3/8-T25 221711 T25 60 – 24 3 10
KG3/8-T27 221712 T27 60 – 24 3.8 10
KG3/8-T30 221713 T30 60 – 24 3.8 10
KG3/8-T40 221714 T40 60 – 24 4.3 10
KG3/8-T45 221715 T45 60 – 24 5 10
KG3/8-T47 221716 T47 60 – 24 5 10
KG3/8-T50 221717 T50 60 – 24 5.5 10
KG3/8-T55 221718 T55 60 – 24 5.5 10

All specifications without guarantee, errors and omissions excepted.
