Industrial Tools
Torque Systems

Red Rooster RRI-BS Battery Screwdriver

Capacity 3 / 6 / 9 / 12 Nm

Cordless Shut-off Pistol Screwdriver



Updated version ('H2') of the RED ROOSTER battery screwdriver with shut-off. Very well suited for assembly applications with a need of good torque accuracy. Especially in areas where cables and hoses impede handling flexibility, such as interiors of cars, coaches and trains. Models with "W" in the item number can be connected by WLAN to the DWL-B controller for the registration of correct tightenings.



Features RRI-BS



  • Brushless DC motor
  • Lithium-Ion battery, choice for 2.5 Ah or 5.0 Ah capacity
  • LED status indicates OK - NOK - REVERSE - BATTERY LOW
  • Adjustable torque
  • Compact and light weight
  • Contactless trigger and forward / reverse switch for a long lifetime



Features DWL-B



  • Wireless communication
  • Error proofing
  • Prevent missing screw
  • Tightening data storage
  • Multi-tools transmission
  • Barcode scanning function (BCAW & BCPW)
  • Socket Selecting function (BCAW & BCPW)



Scope of Supply



  • Battery Screwdriver
  • Torque Adjust Key # 00-4507



Battery and charger to be ordered separately.






Options / Accs / Spares



  • 20V Li-ion Battery 2.5 Ah # BB200D-325 (0.39 kg)
  • 20V Li-ion Battery 5.0 Ah # BB200D-350 (0.67 kg)
  • Battery Charger # B84192B
  • EU Power Cord # E86B-VD
  • Programmer # B74SC180B



  • Protection Cover (tool)
  • Protection Cover (battery)
  • Torque Adjust Key # 00-4507
  • Tool Holder (depending on model)
Series RRI-BS
Model Item No. Hex [inch] Torque [N·m] Bolt Cp [mm] Speed [rpm] Length [mm] Weight [kg]
RRI-BS3H2 520402 1/4 0.8 - 3 4 200–500 203 1.0
RRI-BS6H2 520405 1/4 1.5 - 6 5 300–1000 203 1.0
RRI-BS9H2 520408 1/4 2.0 - 9 5 300–800 203 1.0
RRI-BS12H2 520411 1/4 2.5 - 12 6 250–800 203 1.0
Series RRI-BSW
Model Item No. Hex [inch] Torque [N·m] Bolt Cp [mm] Speed [rpm] Length [mm] Weight [kg]
RRI-BSW3H2 520402-W 1/4 0.8 - 3 4 200–500 203 1.0
RRI-BSW6H2 520405-W 1/4 1.5 - 6 5 300–1000 203 1.0
RRI-BSW9H2 520408-W 1/4 2.0 - 9 5 300–800 203 1.0
RRI-BSW12H2 520411-W 1/4 2.5 - 12 6 250–800 203 1.0

Specification according to manufacturer. All information without guarantee, subject to change without notice. Weight without battery.



Models with "W" in the article number can be connected by WLAN to the DWL-B controller for the registration of correct tightenings.
