Torque Analyzers
The international standard (DIN) EN ISO 6789 is decisive for testing/calibrating hand-held torque tools, for example. According to this standard, a measuring device should be four times more accurate than the tool being tested. This means that a testing device with an accuracy of ± 1% can generally be used for signalling torque wrenches and screwdrivers (type II). However, for indicating torque wrenches and screwdrivers (type I), a measuring device with an accuracy of ± 0.5% or better would be required.
- Torque Gauges
- For testing precision mechanical or electronic components, e.g. small motors, encoders, potentiometers, etc.
- Also for orthodontic springs or the like
- For testing fine torque screwdrivers
- Torque span 0.05 ... 200 cNm
- Cap Torque Meters
- For testing bottle caps, e.g. on medicine or cosmetics containers, beverage bottles or food jars, etc.
- Also suitable for testing starting torque, spring force, torsion, etc.
- Torque span 0.002 ... 2000 cNm
- Torque Checkers
- For spot check/routine check of torque setting
- Standard accuracy ± 1%
- Torque span 0.02 to 10,000 Nm
- Torque Testers
- For standardized / traceable test series
- High accuracy of ± 0.25% or ± 0.5%
- Torque span 0.05 to 1,000 Nm
