Industrial Tools
Torque Systems

Special Open End Head 'Mini'

Centre Line 17.5 mm

Interchangeable open end head for use with the SR MiniTorq preset clicker torque wrench. Further A/F's and/or special manufacturings available on request.



Key Features



  • According to DIN 3110.
  • Fixed by 2 x M3 screws.
  • Forged alloy steel, chrome plated.
MOE (mm)
Model Item No. A/F [mm] Cent. dist. [mm] Weight [kg]
MOE-5 R809651 5 17.5 n. a.
MOE-5.5 R809652 5.5 17.5 n. a.
MOE-6 R809653 6 17.5 n. a.
MOE-7 R809654 7 17.5 n. a.
MOE-8 R809655 8 17.5 n. a.
MOE-10 R809656 10 17.5 n. a.

All specifications without guarantee, errors and omissions excepted.

MOE (inch)
Model Item No. A/F [inch] Cent. dist. [mm] Weight [kg]
MOE-3/16 R809627 3/16 17.5 n. a.
MOE-1/4 R809628 1/4 17.5 n. a.
MOE-5/16 R809629 5/16 17.5 n. a.
MOE-11/32 R809630 11/32 17.5 n. a.
MOE-3/8 R809631 3/8 17.5 n. a.

All specifications without guarantee, errors and omissions excepted.
