Sturtevant Richmont ExacTorq Adjustable Torque Screwdriver

Capacity 74 cNm // 100 ozfin

Micrometer Adjustable Torque Screwdriver



Say goodbye to guesswork with ExacTorq's end-mounted DigiLock mechanism, allowing for precise torque adjustments in single-digit increments. The positive locking detent ensures your settings remain secure.



The ExacTorq features an advanced tri-lobular handle design, providing enhanced leverage, comfort, and grip control. This ergonomic design reduces strain and potential repetitive-motion injuries by engaging major muscle groups. Comfortable for all users, the ExacTorq performs flawlessly for both men and women on the assembly line.



The ExacTorq Adjustable Torque Screwdriver is ideal for any application where:



  • Low torque is needed.
  • Single-digit torque incrementation is needed.
  • Superior ergonomics are needed.



Its‘ unique ergo-grip design for enhanced comfort and handling translates into improved operator technique and lower risk of repetitive motion injury. Enhanced comfort translates into enhanced accuracy. The operator cannot overtorque. A clutch releases automatically when desired torque has been achieved. The anti-backlash design enhances the repeatability.



Additionally, the ExacTorq is comfortable in even the smallest of hands, performing flawlessly when used by women and men on the assembly line. To operate, simply dial torque setting and insert bit.



Key Features



  • DigiLock Control Mechanism revolutionizes manual torque adjustment
  • Positive locking detent secures selected torque value
  • Can be used in both right and left hand directions
  • Designed to meet or exceed ASME B107.300-2010 and ISO 6789 specifications, each ExacTorq ships with a calibration certificate from our ISO/IEC 17025 Accredited Laboraty
  • Operator cannot over-torque; clutch releases automatically when desired torque has been achieved
  • Uses standard bits, sockets, and adapters
  • Anti-backlash design enhances repeatability
  • Accuracy of ± 6% indicated value



Scope of Supply



  • ExacTorq screwdriver
  • Operating manual
  • ISO/IEC 17025 calibration certificate






Options / Accs / Spares



ExacTorq
Model Item No. Torque Range [ozf·in] Torque Range [cN·m] Graduation Length [mm] Weight [kg]
ExacTorq 74 R 810046 15 - 74 1 171 0.17
ExacTorq 100 R 810045 20 - 100 1 171 0.17

Table showing specifications by the manufacturer. It is recommended to primarily use in medium performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (maximum capacity), a larger model or tool might be more advisable.



All technical data without guarantee, errors and omissions excepted.
