Tohnichi 5TM Torque Meter

Capacity 1 / 1.5 / 2.5 / 5 / 7.5 mNm

Analog Torque Meter for Low Torque Applications



Tohnichi's Torque Meter is suitable for checking torque on bottle caps, starting torque test, strength test, and twisting test, etc.



TM is equipped with 4 poles that can change positions according to the object's shape and hold it firmly during testing.



There is no need to fix the tester on the table with bolts, which gives greater portability. With the optional calibration equipment, the torque tester can be calibrated at the customer side.



Features



  • Bi-directional (right/left)
  • Accuracy ± 2%
  • Large scale for easy reading
  • Clamping fixture with 4 poles
  • Ergonomically designed and adapted for Colour Vision Deficiencies



Scope of Supply



  • Torque Meter 5TM
  • Rubber nails
  • Operating manual (eng)
  • Traceable Certificate of Calibration
5TM series – SI Model (mNm) *
Model Item No. Torque Range [mN·m] Graduation Chuck ØD [mm] Weight [kg]
5TM1MN T251201 0.2 - 1.0 0.05 6 - 58 0.3
5TM1.5MN T251204 0.3 - 1.5 0.05 6 - 58 0.3
5TM2.5MN T251207 0.5 - 2.5 0.1 6 - 58 0.3
5TM5MN T251210 1.0 - 5.0 0.2 6 - 58 0.3
5TM7.5MN T251213 1.5 - 7.5 0.2 6 - 58 0.3
5TM series – Metric *
Model Item No. Torque Range [gf·cm] Graduation Chuck ØD [mm] Weight [kg]
5-OT10 T251202 2 - 10 0.5 6 - 58 0.3
5-OT15 T251205 2 - 15 0.5 6 - 58 0.3
5-OT25 T251208 5 - 25 1 6 - 58 0.3
5-OT50 T251211 10 - 50 2 6 - 58 0.3
5-OT75 T251214 10 - 75 2 6 - 58 0.3
5TM series – Imperial *
Model Item No. Torque Range [ozf·in] Graduation Chuck ØD [mm] Weight [kg]
5TM0.15Z T251203 0.02 - 0.15 0.005 6 - 58 0.3
5TM0.2Z T251206 0.04 - 0.2 0.01 6 - 58 0.3
5TM0.35Z T251209 0.05 - 0.35 0.01 6 - 58 0.3
5TM0.7Z T251212 0.3 - 0.7 0.02 6 - 58 0.3
5TM1Z T251215 0.2 - 1.0 0.05 6 - 58 0.3

NOTES: 5TM series models are made to order and are non-returnable.



All specifications without guarantee, errors and omissions excepted.
