Pre-Lock Adjustable Click Type Torque Wrench
This wrench type is a combination of preset and adjustable type torque wrench. They are equipped with a torque scale but to change the set torque an auxiliary tool is required, making inadvertent changes to set torque difficult during a tightening operation. This effectively prevents human errors. The aux key for torque adjustment is a standard accessory.
The ratchet head has 24 teeth with a 15 degree operating range, allowing for use in space-limited working conditions. A clear “Click” sound signals tightening completion upon reaching the set torque.
Key Features
Scope of Supply
Options / Accs / Spares
| Model | Item No. | Torque Range [N·m] | Graduation | SqD [inch] | Length [mm] | Weight [kg] |
|---|---|---|---|---|---|---|
| PQL5N | T212100 | 1 - 5 | 0.05 | 1/4 | 153 | 0.15 |
| PQL10N | T212102 | 2 - 10 | 0.1 | 1/4 | 190 | 0.19 |
| PQL15N | T212105 | 3 - 15 | 0.1 | 1/4 | 190 | 0.19 |
| PQL25N | T212108 | 5 - 25 | 0.25 | 3/8 | 220 | 0.25 |
| PQL50N | T212111 | 10 - 50 | 0.5 | 3/8 | 250 | 0.40 |
| PQL100N4 | T212114 | 20 - 100 | 1 | 1/2 | 320 | 0.65 |
| PQL140N | T212117 | 30 - 140 | 1 | 1/2 | 386 | 0.75 |
| PQL200N4 | T212120 | 40 - 200 | 2 | 1/2 | 470 | 1.4 |
| PQL280N | T212123 | 40 - 280 | 2 | 3/4 | 670 | 2.0 |
| PQL420N | T212125 | 60 - 420 | 2 | 3/4 | 972 | 3.4 |
| Model | Item No. | Torque Range [kgf·cm] | Torque Range [kgf·m] | Graduation | SqD [inch] | Length [mm] | Weight [kg] |
|---|---|---|---|---|---|---|---|
| 50PQL | T212101 | 10 - 50 | – | 0.5 | 1/4 | 153 | 0.15 |
| 100PQL | T212103 | 20 - 100 | – | 1 | 1/4 | 190 | 0.19 |
| 150PQL | T212106 | 30 - 150 | – | 1 | 1/4 | 190 | 0.19 |
| 225PQL | T212109 | 50 - 250 | – | 2.5 | 3/8 | 220 | 0.25 |
| 450PQL | T212112 | 100 - 500 | – | 5 | 3/8 | 250 | 0.40 |
| 900PQL4 | T212115 | 200 - 1000 | – | 10 | 1/2 | 320 | 0.65 |
| 1400PQL | T212118 | 300 - 1400 | – | 10 | 1/2 | 386 | 0.75 |
| 1800PQL4 | T212121 | 400 - 2000 | – | 20 | 1/2 | 470 | 1.4 |
| 2800PQL | T212124 | – | 4 - 28 | 0.2 | 3/4 | 670 | 2.0 |
| 4200PQL | T212126 | – | 6 - 42 | 0.2 | 3/4 | 972 | 3.4 |
| Model | Item No. | Torque Range [lbf·in] | Torque Range [lbf·ft] | Graduation | SqD [inch] | Length [mm] | Weight [kg] |
|---|---|---|---|---|---|---|---|
| PQL50I-2A | T212104 | 10 - 50 | – | 0.5 | 1/4 | 190 | 0.19 |
| PQL100I-2A | T212107 | 20 - 100 | – | 0.5 | 1/4 | 190 | 0.19 |
| 225PQL-A | T212110 | 40 - 200 | – | 2 | 3/8 | 220 | 0.25 |
| 450PQL-A | T212113 | 100 - 400 | – | 5 | 3/8 | 250 | 0.40 |
| 900PQL4-A | T212116 | – | 15 - 75 | 1 | 1/2 | 320 | 0.65 |
| 1400PQL-A | T212119 | – | 30 - 100 | 1 | 1/2 | 386 | 0.75 |
| 1800PQL4-A | T212122 | – | 30 - 150 | 2 | 1/2 | 470 | 1.4 |
Data according to specifications by the manufacturer. It is recommended to primarily use in moderate performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (max capacity), a larger model or tool might be more advisable.
SI unit products and metric unit products are compliant with ISO 6789:2017 starting January 2022. Calibration Certificates will be different from older products. American unit products are not compliant with ISO 6789:2017.
All technical data without guarantee, errors and omissions excepted.
