Dual Square Drive Clicker Torque Wrench for Bi-directional Tightening
Useful for both clockwise and counterclockwise tightening using the same torque wrench with dual square drive. For tightening wheel nuts of large trucks, buses, etc. Torque management of screws on both sides.
Torque setting is easy to adjust by knob and scale. A clear “click” sound signals tightening completion upon reaching the set torque. The ratchet head has 24 teeth with a 15-degree operating range, allowing for use in space-limited working conditions.
DQLE1000N2 and DQLE750N2 models are suitable for tightening the wheel nuts of large motor vehicles. Use a through-hole socket (for power tools) for a square drive of 1 inch or larger.
Features
Scope of Supply
Options / Accs / Spares
| Model | Item No. | T Range [N·m] | Graduation | SqD [inch] | Length [mm] | Weight [kg] | Handle |
|---|---|---|---|---|---|---|---|
| DQL200N4 | NEW | 40 - 200 | 2 | 1/2 | 489 | 1.4 | BK |
| DQL280N | NEW | 40 - 280 | 2 | 3/4 | 692 | 2.0 | BK |
| DQLE550N2 | NEW | 100 - 550 | 5 | 3/4 | 1189 | 4.3 | MH |
| DQLE750N2 | NEW | 150 - 750 | 5 | 3/4 | 1342 | 5.7 | MH |
| DQLE1000N2 | NEW | 200 - 1000 | 5 | 1 | 1515 | 7.9 | MH |
Data according to specifications by the manufacturer. It is recommended to primarily use in moderate performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (max capacity), a larger model or tool might be more advisable.
SI unit products and metric unit products are compliant with ISO 6789:2017 starting January 2022. Calibration Certificates will be different from older products. American unit products are not compliant with ISO 6789:2017.
Handle Design: 'BK' = black resin grip; 'MH' = knurled metal handle.
All technical data without guarantee, errors and omissions excepted.
