Measuring Systems for Power Tools

High-precision torque measuring systems for pneumatic or electric impulse tools, non-impacting torque drivers, as well as torque wrenches. Modular composable of the desired display unit and suitable torque transducers, with optional angle measurement for many models. Some can be extended with 'OMS' PC software for tool data management, statistical evaluation, trace graphs and much more.



  • CRANE data collector TorqueStar Lite:
    - Static Accuracy ± 0.25% FSD of connected transducer
    - Monochrome OLED display
    - 4 measurement modes: Track, Peak, Click, Pulse
    - Basic statistics: count, range, mean, min, max, standard deviation
    - Data export via micro USB
    - Compatible with CheckStar UTA / CheckStar Multi / Stationary UTA / WrenchStar Multi (via cable) / Auto-T-Switch



  • CRANE data collector TorqueStar Plus:
    - same as “Lite”, but additional/deviating:
    - Backlit 4-colour display (4 inch)
    - 5 measurement modes: Track, Peak, Click, Pulse, Audit
    - Data export alternatively as CSV file (USB memory)
    - Compatible with OMS software also



  • CRANE data collector TorqueStar Pro:
    - same as “Plus”, but additional/deviating:
    - Graphic 4-colour display (4 inch) for traces and graphic analysis
    - 8 measurement modes: Track, Peak, Click, Pulse, Audit, MoveOn, Re-tighten, Yield
    - Jobs and rounds
    - Wireless communication
    - 16 GB memory (SDHC)
    - Advanced statistics: count, range, mean, min, max, variance, Cm, Cmk, Cp, Cpk



  • CRANE series CheckStar Multi:
    - Inline rotary torque transducer, optionally with high-resolution angle encoder (0.125°)
    - Torque accuracy ± 0.25% FSD
    - 3-colour status feedback via all-round LED
    - Compatible with radio module “RFm” for wireless pairing with TCI Multi / TorqueStar Pro / IQVu2
    - Capacity 1 / 2 / 5 / 10 / 20 / 25 / 50 / 75 / 100 / 180 / 250 / 500 / 750 / 1400 / 3000 / 5000 Nm



  • CRANE series CheckStar UTA:
    - Inline rotary torque transducer, optionally with angle encoder (0.5°)
    - Torque accuracy ± 0.25% FSD
    - Plug & play with Crane data collectors (Auto-ID)
    - Compatible with TorqueStar Lite / TorqueStar Plus / TorqueStar Pro / IQVu2
    - Capacity 1 / 2 / 5 / 10 / 20 / 25 / 50 / 75 / 180 / 250 / 500 / 750 / 1400 / 3000 / 5000 Nm



  • CRANE series Stationary UTA:
    - Static torque transducer with round mounting flange
    - Torque accuracy ± 0.25% FSD
    - Plug & play with Crane data collectors (Auto-ID)
    - Compatible with TorqueStar Lite / TorqueStar Plus / TorqueStar Pro / IQVu2 / Z-Pro TTB
    - Capacity 3.5 / 5,6 / 11 / 28 / 67 / 135 / 270 / 540 / 1000 / 1700 / 3000 / 5000 Nm
